Support Intel® AMT8.0 processor
-
Supports above and 3rd generation Intel® Core™ i3, i5, i7 mobile processor
-
320GB HDD
-
4 GB DDR3 RAM expandable to 16GB
-
1 x Display Port & 1 x DVI-I/VGA Port with Converter
-
1 x RS232 Port, 2 x USB 2.0 and 3 x USB 3.0
-
mSATA for expansion options
-
Optional SSD drives available
?
|
Wifi Kit |
AOWIFI-DE |
Wifi card with External Antenna |
|
CPU |
Intel® i5-2510e Chipset: Intel® QM67 AOPEN Thermal Module |
|
Graphics |
Chip: HD3000/4000 |
|
WatchDog Timer |
1 ~ 255 sec/min |
|
Memory |
4GB DDR3 1333/1600 Mbps (2 Slot) expandable to 16 GB OS dependent |
|
Storage |
Standard with 320 GB HDD Can also be supplied with SSD Drive |
|
Connectivity |
1 x Display Port |
|
1 x DVI-I/VGA Port (with Converter) |
|
|
10/100/1000Mb Ethernet Port |
|
|
2 x USB 3.0 Ports |
|
|
2 x USB 2.0 Ports on front Panel |
|
|
1 x RS-232 Serial (COM) Port |
|
|
1 x mini Card Slot Full size supports mSATA |
|
|
1 x Line-out & 1 x Mic in |
|
|
Audio |
Type : Realtek HD Audio Codec ALC662 Channel : Stereo |
|
Indicators |
Power & HDD Indicator Blue on front panel |
|
Size (W x D x H) |
166mm x 157mm x 48mm |
|
Weight |
1.12 Kg |
|
Operating Temperature |
0 ~ 50°C |
|
Storage Temperature |
-30 ~ 60°C |
|
Relative Humidity |
10% ~ 95% @ 50°C non condensing |
|
Power Supply |
90W (20V, 4.5A) External AC Adapter |
|
MTBF |
40000 Hrs |
|
Certification |
C-tick, CE, FCC, UL |
