Thermal Transfer Technology
-
Hi-Open™ housing for easy media loading
-
EPL2 programming language compatible
-
Self-contained mechanism for durable operation
-
Compact design
-
Single button control panel
-
Auto switching external power supply
-
Standard tear-bar for perforated tags
-
Ethernet 10/100, RS-232 Serial and USB 2.0
-
Label-making software included
|
Labels |
LAB100100PWS25P |
Plain glossy Labels 100 x 100 White, Permanent adhesive, Perforated, 25 mm Core |
|
LAB100150PWS40P |
Plain Labels 98 x 148 White, Perforated, Permanent adhesive, 40mm Core |
|
|
LAB10173PGWS40 |
Plain Glossy Labels 101 x 73 White, Permanent adhesive, 40mm Core. |
|
|
Many other sizes available |
Please Call our Sydney Office on: 02-8875 4544 |
|
Printing Method |
Thermal Transfer & Direct Thermal Printing |
|
|
CPU |
32bit RISC CPU |
|
|
Printing Speed (Max.) |
up to 102 mm/sec (4 inches/sec) |
|
|
Fonts |
1 Scalable, 8 Bitmap resident |
|
|
True type Download |
Supported Standard |
|
|
Emulations (languages) |
Zebra® ZPL-II®, Datamax® I-Class™ & DMX400™, Cross-Emulation™ automatic detection. BASIC Interpreterfor Data stream processing and ticket emulations. |
|
|
Media Type |
Roll or Fanfold; Continues or Perforated; die cut labels; Tags & Tickets |
|
|
Media Sensing |
Fixed transmissive sensor, Reflective Sensor, central aligned |
|
|
Resolution/Dot pitch |
203 dpi, 8 dots/mm |
|
|
Media width (Min-Max) |
25.4 – 118 mm |
1 – 4.65 inches |
|
Media Roll Size (Max) |
127 mm, 5 inches (Internal) |
|
|
Media Thickness (Min-Max) |
0.06 – 0.20 mm |
0.003 – 0.008 inches |
|
Printing width (Max) |
108 mm |
4.25 inches |
|
Bar-code Symbologies |
Code 39, Code 93, EAN8/13 (add on 2&5), UPC-A/E (add on 2&5) Interleaved 2 of 5, Interleaved 2 of 5 with Shipping Bearer Bars, Codabar, Code128 (subset A, B, C), EAN-128, RPS 128, UCC128, UCC/EAN-128 K-Mart, RandomWeight, Post NET, ITF 14, China Postal code, HIBC, MSI, Plessey, Telepen, FIM and GS1 DataBar MaxiCode, PDF417, Datamatrix code, QR code, Micro PDF417, Micro QR Code, Aztec Code |
|
| Standard Interface |
Serial |
RS232C, Baudrate from 2400-115200 |
|
USB |
Full Speed USB1.1 |
|
|
Ethernet |
IEEE 802.3 10/100Base-TX |
|
|
Memory |
SDRAM |
16 Mb |
|
Flash Memory |
8 Mb, 4 Mb available for user |
|
|
Weight |
2.5 Kg |
|
|
External Dimensions (W x D x H) |
224 x 254 x 170 mm |
|
|
Operating temp. range |
5 to 40 ºC, Humidity 30 to 85% |
|
|
Storage temp. range |
-20 to 50 ºC, Humidity 10 to 90% |
|
|
Safety compliance |
FCC : class A, CB, CCC, CE(EMC), NOM, S-Mark, C-Tick |
|
