High Speed (80mm/sec) Direct Thermal Printing
-
Drop in Paper loading
-
Two Colour Printing (with Special Paper)
-
Barcode Printing
-
Compatibility (ESC/POS)
-
Easy to use configuration software
-
Low cost Thermal Printing
-
User-changeable interface
-
Available in Ivory & Black
-
Can also be hung upright
|
Paper |
T5750 |
Thermal 57 X 50 Paper Roll |
|
T5770 |
Thermal 57 x 70 Paper Roll |
|
Printing Method |
Line Thermal Dot Printing |
|
|
Printing Width |
58mm Paper: 48mm/384 Dot/lines |
|
|
Dot Pitch |
8 x 8 dots/mm (203 dpi) |
|
|
Printing Speed (Max.) |
approx. 80 mm/Sec |
|
|
Number of Columns |
Font A – 32 columns |
|
|
Font B – 42 columns |
||
|
Font C – 48 columns |
||
|
Character Size |
Font A:1.5 ×3.00mm |
|
|
Font B:1.13 ×2.13mm |
||
|
Font C: 1.0 x 2.0mm |
||
|
Character Table |
Alphanumeric Character (Font A, B & C) |
|
|
Code page 437,850,852,857,860,863,865,866,Katakana,Windows code |
||
|
Bar-code Type |
UPC-A/E,JAN-13/8,ITF,Code 39,Code 128,CODABAR,Code 93 |
|
|
Line Spacing |
4.23mm (1/6 inch), can be set by a command |
|
|
Paper feed method |
Friction |
|
|
Paper Type |
Thermal Paper Roll |
|
|
Paper Width |
58 ± 0.5mm |
|
|
Paper Roll Diameter |
Max Ø 83.0mm |
|
|
Paper Supply Method |
Easy Paper Loading, Drop in and Print |
|
|
Emulation |
ESC/POS |
|
|
Print Buffer |
4K bytes or 45 bytes (dipswitch selectable) |
|
|
NV Memory |
256 Kbytes |
|
|
Sensors |
Paper Near End Sensor, Paper End Sensor , Rear Cover Open Sensor |
|
|
Standard Interfaces Available |
Parallel |
IEEE1284 and Centronics Compliant |
|
Serial |
RS232C |
|
|
USB |
||
|
Driver available |
Windows 2000/NT/XP/2003 server, OPOS |
|
|
Software Utilities |
Firmware/NV Image download |
|
|
Weight |
Printer: 430g, Power adapter: approx. 240g |
|
|
External Dimensions (W x D x H) |
106 x 170 x 116.5 mm |
|
|
Reliability |
Head |
100,000,000 pulses or 100 Km |
|
EMC/Safety Standards |
UL, C-UL, FCC Class A, TUV-GS, CE |
|
|
Power Supply (Adapter) |
Input: AC100 ~240V± 10%(include) Output: DC 8.5V |
|
