Automatic Scanning Operation
-
Firmware updates via Flash ROM
-
Supports commonly used interfaces including USB and Keyboard Wedge
-
Custom edit the bar code data
-
Powerlink, user replaceable cables
-
Field Replaceable Window
-
RSS Decoding Capability
-
Sunrise 2005 compliant
-
OPOS and JPOS system compatible
-
Easy programming using MetroSet® Windows®-based software or MetroSelect® barcodes
-
Multiple Beeper tones
-
Build in EAS antenna
|
Scan pattern |
5 fields of 4 Parallel Lines (Omni-directional) |
|
Scan Speed |
2000 scan Lines per second |
|
Width of Field |
38mm at 15mm, 135 mm at 191 mm |
|
Depth of Field |
0 ~ 215 mm for 13 mil bar codes |
|
Light Source |
Visible Laser Diode 650 nm +/- 10 nm |
|
Decoding Capability |
Decodes all standard 1D, RSS14, RSS Limited and RSS expanded Barcodes |
|
Communications |
PC Keyboard wedge, RS232, OCIA, Light pen emulation, IBM 468X/469X, Stand Alone Keyboard, USB. |
|
Shock |
Designed to withstand 1.2 m drops |
|
Dimensions (H x D x W) |
Scanner 16.8 x 19.9 x 18.5 cm Stand 6.4 x 6.4 x 15.5 |
|
Weight |
1.2 Kg |
|
Factory Warranty |
3 years |
|
Laser Class |
IEC60285-1 Class 1 |
|
EMC |
FCC, ICES-003 & EN55022 Class A |
