Automatic Scanning Operation
-
Patented CodeGate® Technology
-
Multiple onboard interfaces including USB and Keyboard Wedge
-
Code Select® function, Scans up to 7 bar-codes in one scan
-
Automatic Cable detection
-
RSS Decoding Capability
-
Sunrise 2005 compliant
-
OPOS and JPOS system compatible
-
TotalFreedom™, can load custom application directly into the imager
-
Multiple Beeper tones
-
Build in EAS antenna
|
Adaptor |
AD-MS7820 |
5V Regulated Power Supply |
|
Beeper Operation |
7 tones or no beep |
|
Indicator |
LED, Blue= unit powered ready to scan, White= Good read |
|
Width of Field |
55mm x 35mm @ face 185mm x 110mm @ 152mm |
|
Depth of Field |
0 ~ 152 mm for 13 mil bar codes |
|
Light Source |
LED 645 nm +/- 7.5 nm |
|
Decoding Capability |
Decodes all standard 1D codes, GS1, PDF417, microPDF, MaxiCode, Data Matrix, QR Code, UCC, EAN Composites, Postals, Aztecs |
|
Communications |
PC Keyboard wedge, RS232, 46xx RS485, USB |
|
Shock |
Designed to withstand 1.5 m drops |
|
Light Levels |
up to 100000 Lux |
|
Power |
Operating: 2.3W Standby: 1.7W |
|
DC Transformer |
12V, 1.25A |
|
Dimensions (H x D x W) |
Scanner 15 x 8 x 8.3 cm |
|
Weight |
340 g |
|
Factory Warranty |
3 years |
|
Laser Class |
EN60285-1 Class 1 |
|
EMC |
FCC Class B |
