1D Laser or 2D Adaptus 5 Imaging Engine
-
Decodes all major 1D, 2D symbologies and OCR-A/B depending on Scan engine
-
Class2 Bluetooth® Communications
-
19 Key Keyboard for basic Data entry
-
Optional NFC and or GPS Receiver
-
Large data memory (4MB)
-
IP65 & 1.5m Drop spec
-
Bright 1″ OLED display
-
Rechargeable Li-Poly battery with user-accessible compartment for easy replacement
-
Powerful keyboard emulator with keyboard wedging, application generation, DB look up and inventory program.
?
|
Battery |
KDC400BATT |
Rechargeable Battery (1200 mAh) for KDC-350/400 |
|
Scan Engine |
2D Standard Range or Special Focus Adaptus 5 752 x 480 CMOS Sensor Scan range SR: 53~335mm SF: 51~226mm depending on Barcode size Range of Laser Scan Engines |
|
Display |
1″ OLED |
|
Keyboard |
19 Key |
|
Communication |
Bluetooth V2.1+EDR, Class 2, HID/SPP USB to Serial Interfaces: Built in ultra mini USB port Optional GPS: PT9250 48 Channel Receiver Optional NFC: Ultralight, MIFARE Ultralight C tag |
|
Symbologies supported |
All major 1D & 2D Bar-codes depending on scan engine used |
|
Operation |
CPU: ARM 7 32-bit Proprietary OS RTC: Supports year, month, day, hour, minute, second (leap year supported) |
|
Memory |
FlashROM: 256KB, 4MB User Memory RAM: 64KB |
|
Power |
Rechargeable Battery: Lithium-ion 3.7V 1200mAh Charged through the USB |
|
Operating Temperature |
-10 to 50 °C |
|
Storage Temperature |
-20 to 60 °C |
|
Humidity |
5 – 90 % (non-condensing) |
|
Sealing |
IP65 |
|
Drop Test |
1.5 m / 5 ft drop onto concrete surface |
|
Warranty |
1 Year limited Factory Warranty (not on cable) |
|
Dimensions (W x H x D) |
Scanner 43 x 94 x 24 mm |
|
Weight |
Scanner 85 g |
|
Product Compliance |
CE, FCC, MIC, TELEC |
