Intel Celeron® Processor 2.0GHz
-
Innovative Compact Design
-
Die-cast aluminium cabinet
-
Optional SSD drive
-
Exceptional Energy Efficiency
-
Mobile Intel® GL40 Express Chipset
-
Sliding latch provides security
-
Lock down via Kensington lock
-
Revolutionary convection cooling solution
-
Fan-less operation for increased reliability
-
Energy Star 5.0 qualification
-
VESA wall mountable
-
Easy and Efficient Serviceability with single hinged tool free design
?
|
Memory upgrade |
NCR60R2000 |
2GB DDR3 Memory upgrade |
|
Expansion cards |
NCR40-3USB12 |
I/O card /w 3 extra 12V USB and Daughter board |
|
LCD Display |
NCR5942H15-B |
15″ inch LCD Display |
|
12″ inch LCD Display |
||
|
Touch Monitors |
15″ inch LCD Capacitive Touch Monitor with Powered USB |
|
|
15″ inch LCD resistive Touch Monitor with Serial Interface |
||
|
Keyboards |
NCR2336 |
Small 78-Key Programmable POS Keyboard with 3 Track MSR |
|
SPOS G86-61411 Black 14″ USB keyboard with 3-track magnetic stripe reader and touchpad. 123 Key QWERTY plus 60 Programmable keys |
||
|
Cash Drawers |
NCRHdr |
NCR Compact Hospitality Cash Drawer, Charcoal |
|
NCRMdr-B |
NCR Mid-range Cash Drawer, Dark Grey |
|
|
Printers |
NCR Single Station Thermal POS Printer |
|
|
NCR 2-station Hybrid Printer |
|
CPU |
Intel Celeron® 900 2.2Ghz CPU (1MB L2 Cache, FSB 800MHZ) |
|
Memory |
1 GB DDR3 RAM 800 MHz expandable to 4 GB |
|
Storage |
Standard with 2.5-inch 160GB SATA Hard Disk Drive |
|
Connectivity |
4 Powered RS-232 (selectable 0/5/12V) |
|
1 PS2 Port |
|
|
5 total, expandable to 8 |
|
|
1 x VGA Port 1 x DVI port for LCD Monitor |
|
|
1 Cash Drawer Port (Controls 2 drawers with optional Y-cable) |
|
|
10/100Mb Ethernet Port |
|
|
Expansion slot for proprietary expansion card |
|
|
Operating Systems |
Windows ® Embedded POSReady 2009 |
|
Power management |
150W Power Supply (external) External power supply enables easy swap |
|
Energy Star 5.0 Qualification |
Windows and SLEPOS 11 operating systems purchased from NCR are defaulted to support ENERGY STAR 5.0 power settings. If an operating system is not purchased from NCR, the RealPOS 40 will ship with an open source Linux operating system defaulted to support ENERGY STAR 5.0 power settings for compliance purposes. |
|
Housing |
Die Cast Aluminium |
|
Diagnostics |
2 Colour LED’s provide diagnostic feedback |
|
Software Support |
NCR OPOS and JavaPOS support |
|
Serviceability |
Open Hinged cabinet Tool free access to internal components Tool free replacement of Hard disk Drive |
|
Size (W x D x H) |
254 x 226 x 76mm |
|
Weight |
Terminal with power supply: 3.63 Kg |
|
Operating Temperature |
0 ~ 40°C |
|
Relative Humidity |
10% ~ 90% non condensing |
|
Power Supply |
150W-12V External Power supply |
