Maximum Resolution 1.3MP
Application Environment Indoor
Image Sensor Progressive Scan CMOS
Superior Low Light Sensitivity Yes
Minimum Illumination Color: 0.1 lux at F1.4
Lens Vari-focal, f2.8-12mm / F1.4, Fixed iris, Manual focus
Viewing Angle Adjustment Pan: 0°-350°,
Tilt: 17°-163°,
Rotate: 0°-350°
Lens Mount Board mount
Horizontal Viewing Angle 83.0°-31.1°
Compression H.264 (Baseline/ Main/ High profile), MJPEG
Maximum Frame Rate vs. Resolution 30 fps at 1280 x 960
60 fps at 1280 x 720
30 fps at 800 x 600
30 fps at 640 x 480
15 fps at 320 x 240
Horizontal Resolution (TV lines) 950 TVL
Multi-Streaming Dual streams
Wide Dynamic Range Basic WDR (88 dB)
Digital Noise Reduction DNR
S/N Ratio 52 dB
Audio 2-way (Line-in, Line-out)
Network Protocol & Service TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
Network Connector RJ-45
Digital Input/Output 1/1
Local Storage MicroSDHC/MicroSDXC memory card slot (card not included)
Power Source PoE Class 2
Environmental Casing Vandal Resistant (IK09)
Bundled Accessories No
Mount Type Surface, Pendant, Wall, Corner, Pole, Flush, Gang Box
Software Based Analytics (require PC based Smart Search Tool, IVS Server or ALPR Server) Face Detection, Motion Detection, Tamper, People Counting, Line crossing, Enter area, Exit area, Appear in area, Missing object, Unattended object, Crowd detection, Forbidden direction, Vehicle Counting, Heat Map, License Plate Recognition, Speed Detection
Client PC Operating System Windows 7, Windows Server 2008, Windows Vista, Windows Server 2003, Windows XP
PC Web Browser IE 8, IE 9, IE 10, IE 11, Firefox with VLC, Chrome with VLC, Safari with Quicktime
ONVIF Compliant Yes
Starting Temperature -10°C ~ 50°C
(14°F ~ 122°F)
Operating Temperature -10°C ~ 50°C
(14°F ~ 122°F)
Approvals CE, FCC, IK09, UL (for optional PoE injector)
Warranty 3 Years
