802.11n 2.4/5 GHz 2.5/4 dBi Dual-band Mini MIMO Ceiling Mount Omnidirectional Antenna with RPSMA Plug Connectors
This dual band 2.4/5 GHz ceiling mount multiple-input and multiple-output (MIMO) omnidirectional antenna is designed to operate with AirTight Networks’ 802.11n sensor SS-300-AT-C-10. The antenna features six integrated 2.4 and 5 GHz dual-band omni antennas in one enclosure, making it an ideal and aesthetically pleasing antenna for indoor use.
Frequency Range : 2400 ~ 2483 / 5150 ~ 5850 MHz
Bandwidth : 83 / 700 MHz
Gain : 2.5 / 4 dBi
Vertical Beamwidth : 55° / 60°
Horizontal Beamwidth : 360°
VSWR : = 2.0 / = 2.5
Nominal Impedance : 50 Ohms
Polarization : Vertical
Max Power : 50 Watts
Connector : RPSMA Plug
Pigtail Length : 24”
Dimensions : 7.1” x 5.1” x 1.9”
Weight : 0.68 lbs
Operating Temperature Range : -22°F to +158°F
Mounting Style : Ceiling Mount
