Ultra-thin Multi media all in one Touch System
-
PCT Multi Touch Touchscreen
-
IP65 Grade Dust and Waterproof to the Front
-
18.5” LED LCD Screen 1366 x 768 resolution
-
Equipped with Intel® B980 Pentium® Dual Core 2.4 GHz CPU 2M Cache
-
4G DDR3 memory expandable to 8G
-
Also available with Intel® Core™ i3, i5, i7 mobile Processor
|
Wifi |
AOWIFI-ET |
Optional Wifi card, Antenna build in |
|
CPU |
Intel® 2nd and 3rd generation Intel® B980 Pentium, Intel® Core™ i3, i5, i7 mobile processor TDP=35W |
|
Chipset |
Intel® QM77 |
|
Memory |
DDR3 SO-DIMM socket x 2, max 8 GB, default 4GB |
|
WatchDog Timer |
1 ~ 255 sec/min |
|
Storage |
We stock Standard 320G HDD Also available with SSD |
|
LCD |
18.5″ LED LCD Display |
|
Brightness |
250 nits |
|
Resolution |
1366 x 768 |
|
Aspect Ratio |
16:9/HD |
|
Touch Panel |
PCT Multi Touch Surface (10 point touch) Pencil Hardness = 7H per ASTM D3363 Pen Hitting: more than 20,000,000 times (loading180g) |
|
Connectivity |
2 x RS-232 Ports |
|
2 x USB 2.0 Ports 2 x USB 3.0 Ports |
|
|
1 x HDMI Port |
|
|
1 x 10/100/1000Mb Ethernet Ports |
|
|
Mini card Slot; 1 x Full size (support mSATA), 1 x Half Size |
|
|
Audio |
Realtek ALC886 |
|
Sound |
2W Stereo Speaker in the main unit |
|
Size (W x D x H) |
448mm x 30mm x 284 mm |
|
Weight |
5 Kg |
