Mechanical individual keys with membrane contact switches (FTSC technology)
-
Designed for continuous usage – over 50 mill. Confirmations per key
-
Robust and reliable
-
Programmable magnetic card reader
-
Optional barcode decoder. Data is converted to “scan codes” and transmitted via the PS/2 interface (like normal key operations)
-
43 programmable keys
-
OPOS and JavaPOS for Windows® and Linux, client-server architectures supported
-
Efficient configuration with professional Cherry Tools Software
-
Integrated memory
|
Keyboard |
Key technology: FTSC Inscription technology: Laser Service life, standard key: > 50 million key operations Number of Keys: 104 Number of programmable keys: 43 |
|
MSR |
Magnetic card tracks: Track 1, Track 2, Track 3 Freely programmable Magnetic card standards: ISO 7811/-12, JIS 1/2, AAMVA, Magnetic card reading speed: 8 – 318 cm/s Magnetic card reading cycles: approx. 800000 reading cycles Magnetic card swipe direction: from right to left |
|
Interface |
USB or PS2 |
|
Cable Length |
approx. 1.75 m |
|
Current Consumption |
typ. 35 mA |
|
Operating Temperature |
0°C to 50°C |
|
Storage Temperature |
-20°C to 60°C |
|
Dimensions |
approx. 405 x 220 x 64 mm |
|
Weight |
1.65 Kg |
|
Reliability |
MTBF > 100,000 Hours MCBF > 10 bill. operations |
|
Product compliance |
C-tick, cURus, VDE GS, CE, FCC |
|
Warranty |
2 Year limited factory warranty |
