Solid State Linear Imaging architecture.
-
Sharp Aiming Line
-
Fast Decoding Rate
-
Optical and Audible Read Confirmation
-
Exceptional Read Performance
-
Manual, Presentation Mode or Auto Trigger
-
User replaceable interface cable
-
Powerful, Flexible Architecture
-
Fully Programmable
?
|
Desk holder |
FBCUNIHOLDER |
Universal Desk Holder |
|
Power Supply |
AD5VR10P1.7 |
Optional Power Supply |
|
Scan Engine |
High Performance Linear Imager |
|
Scan Rate |
Dynamic Scanning up to 250 scans/sec |
|
Reading Width |
Typical 62mm on contact reading up to 100mm on distance reading. |
|
Minimum Resolution |
Typical 3 mil (code39, PCS 0.9) |
|
Working Distance |
up to 20 cm from contact on 100% UPC/EAN symbols (measured in 400 lux office environment using A-grade Barcodes) |
|
Illumination |
630nm Visible Red LED |
|
Interfaces |
PS2 Keyboard Wedge or Keyboard direct link |
|
RS-232 (May require external power supply) |
|
|
USB (KBW or COM port emulation) |
|
|
Laser and Wand emulation |
|
|
Symbologies support |
Code 39, Code 39 Full ASCII, Code 32, Code 39 Trioptic, Code 128, UCC/EAN-128, Codabar, Code 11, Code 93, Standard & Industrial 2 of 5, Interleaved & Matrix 2 of 5, German Postal Code, China Postal Code, IATA, UPC/EAN/JAN, UPC/EAN/JAN with Addendum, Telepen, MSI/Plessey & UK/Plessey, GS1 DataBar (formly RSS) Linear, Linear-stacked. |
|
Operating Modes |
Toggle, Trigger, Force, Level, Flash, Diagnostic Alternative, Low power, Presentation. |
|
Drop Specification |
Withstands multiple 1.5m drops to concrete |
|
Environmental Sealing |
IP41 |
|
Operating Temperature |
-10°C to 50°C |
|
Ambient Light Immunity |
0~20000 Lux |
|
Input Voltage |
5VDC ±10% |
|
Weight |
127g (excluding the cable) |
|
Dimension (LxWxD) |
174 x 74 x 31mm |
|
Power Consumption |
Regular operation 150 mA, Low Power Standby: 0.1 mA |
|
Warranty |
1 Year Factory Warranty (not on cable, conditions apply) |
