Solid State Linear Imager Technology, No moving parts!
-
Rugged and compact design
-
Supports GS1 DataBar
-
Bright Sharp Aiming Line
-
Fast Decoding Rate
-
Optical and Audible Read Confirmation
-
Exceptional Read Performance
-
Manual, Presentation Mode or Auto Trigger
-
Universal interface
-
Reads Degraded and damaged bar-codes
-
Powerful, Flexible Architecture
-
Embedded outstanding DataWizard to meet most of the data editing requirements
-
This model replaces the F-760 Series
?
|
Hands-free Stand |
FB760STAND |
Hands-free SmartStand for FBC760/780 scanner. Automatically switched between Hand held scanning and Presentation scanning when scanner put into the stand |
|
Deskholder |
FBCUNIHOLDER |
Universal Desk Holder |
|
Power Supply |
AD5VR10P1.7 |
Optional Power Supply |
|
Scan Engine |
High Performance Linear Imaging Engine |
|
Light Source |
630 nm visible red LED |
|
Scan Rate |
Dynamic scanning rate up to 500 scans/sec |
|
Working Distance |
More then 40cm on 100% UPC/EAN symbols More then 60cm on 20 mil code 39 |
|
Minimum resolution |
Typical 3 mil (Code 39, PCS 0.9) |
|
Print contrast |
20% minimum reflective difference |
|
Pitch Angle |
+/- 65deg. |
|
Skew Angle |
+/- 65 deg |
|
User Interface |
3 LED’s for power, good read and status indications Programmable Beeper |
|
Interfaces |
PS2 Keyboard Wedge or Keyboard direct link |
|
RS-232 (May require external power supply) |
|
|
USB (KBW or COM port emulation) |
|
|
Laser and Wand emulation |
|
|
Symbologies support |
Code 39, Code 39 Full ASCII, Code 32, Code 39 Trioptic, Code 128, UCC/EAN-128, Codabar, Code 11, Code 93, Standard & Industrial 2 of 5, Interleaved & Matrix 2 of 5, German Postal Code, China Postal Code, IATA, UPC/EAN/JAN, UPC/EAN/JAN with Addendum, Telepen, MSI/Plessey & UK/Plessey, GS1 DataBar (formly RSS) Linear, Linear-stacked. |
|
Operating Modes |
Toggle, Trigger, Force, Level, Flash, Diagnostic Alternative, Low power, Presentation. |
|
Ambient Light Immunity |
0~100000 Lux |
|
Drop Specification |
Withstands multiple 1.6m drops to concrete |
|
Environmental Sealing |
IP41 |
|
ESD Protection |
Functional after 15kV discharge |
|
Operating Temperature |
-10°C to 50°C |
|
Input Voltage |
5VDC ±10% |
|
Power Consumption |
Operating : Typical 180 mA @5VDC |
|
Weight |
157g (excluding the cable) |
|
Dimension (LxWxD) |
97.8 x 70.5 x 156.2mm |
|
Warranty |
2 Year Factory Warranty (not on cable, conditions apply) |
