Serial Dot Matrix Printing
-
Up to 2.5 LPS printing speed
-
Panel Mount
-
2K Print Buffer
-
3 ply Printing Capable
-
Data logging device
|
Ribbon |
IR91B |
Black Cassette Ribbon |
|
Paper |
P5757 |
Plain Bond Lint Free Paper 57 x 57 mm |
|
C5757 |
2 Ply Carbonised Paper 57 x 57 mm |
|
Printing Method |
9 Pin Serial dot Matrix |
|
|
Printing Direction |
left to right |
|
|
Number of Columns |
24/40 columns |
|
|
Printing Speed (Max.) |
24 col = approx. 2.5 lines/sec. |
|
|
40 col = approx. 1.8 lines/sec. |
||
|
Character Size |
24 col = 1.62 × 2.4mm |
|
|
40 col = 1.08 × 2.4mm |
||
|
Paper feed method |
Friction |
|
|
Paper Type |
Plain Paper, 2 Ply or 3 Ply |
|
|
Paper Width |
57.5 mm |
|
|
Emulation |
ESC/POS, CBM Mode & STAR Mode |
|
|
Print Buffer |
2K |
|
|
Sensors |
Paper end sensor |
|
|
Standard Interfaces Available |
Serial |
RS232c |
|
Parallel |
Centronics |
|
|
Driver available |
Windows 2000/NT/XP/2003 server, OPOS |
|
|
Weight |
0.4 Kg |
|
|
External Dimensions (W x D x H) |
115 x 119 x 65 mm |
|
|
Reliability |
Mechanism |
MCBF 1 million Lines (40 Columns) |
|
EMC/Safety Standards |
UL, C-UL, FCC class A, TUV-GS, CE marking |
|
|
Power Supply (Adapter) |
AC adaptor 100/120/230, Output 7V DC 5%, 1.9A |
|
