Direct Thermal Printing Technology
-
Hi-Open™ housing for easy media loading
-
Self-contained mechanism for durable operation
-
Compact design
-
Single button control panel
-
Built-in power supply, 220-240V, 50-60Hz
-
Fixed label sensor
-
Standard tear-bar for perforated tags
-
Internal USB interface
-
Media roll holder
-
Optional peeler
-
Label Design Software:
?
|
Labels |
LAB100100TWS40P |
Thermal Labels 100 x 100 White, Permanent adhesive, 40mm Core |
|
Many other sizes available |
Please Call our Sydney Office on: 02-8875 4544 |
|
Printing Method |
Direct Thermal Printing |
|
|
CPU |
32bit RISC CPU |
|
|
Printing Speed (Max.) |
up to 102 mm/sec (4 inches/sec) |
|
|
Fonts |
1 Scalable, 8 Bitmap resident |
|
|
True type Download |
Supported Standard |
|
|
Emulations (languages) |
N/A (EPL specialized for graphic printing) |
|
|
Media Type |
Roll or Fanfold; Continues or Perforated; die cut labels; Tags & Tickets |
|
|
Media Sensing |
Fixed transmissive sensor, Reflective Sensor, central aligned |
|
|
Resolution/Dot pitch |
203 dpi, 8 dots/mm |
|
|
Media width (Min-Max) |
25.4 – 118 mm |
1 – 4.65 inches |
|
Media Roll Size (Max) |
127 mm, 5 inches (Internal) |
|
|
Media Thickness (Min-Max) |
0.06 – 0.20 mm |
0.003 – 0.008 inches |
|
Printing width (Max) |
108 mm |
4.25 inches |
|
Standard Interface |
USB |
Full Speed USB1.1 |
|
Memory |
SDRAM |
16 Kb |
|
Flash Memory |
64 Kb, 4 Kb available for user |
|
|
Weight |
2 Kg |
|
|
External Dimensions (W x D x H) |
168 x 222 x 178 mm |
|
|
Operating temp. range |
5 to 40 ºC, Humidity 30 to 85% |
|
|
Storage temp. range |
-20 to 50 ºC, Humidity 10 to 90% |
|
|
Safety compliance |
FCC : class A, CB, CCC, CE(EMC), UL, c-UL, C-Tick |
|
