The EdgeCore ECS2000 series, Layer 2 managed switches enable networks of all sizes to introduce Gigabit Ethernet to the desktop with management features targeted to meet the needs of the SMB network. They are packed with features and are a cost-effective solution that brings continuous availability, QoS priority queuing with classification, and prioritization at Layer 2.
They deliver wire-speed switching performance on all ports connecting end stations to the corporate network. There are two SFP ports for Gigabit Ethernet fiber uplink flexibility. Optional Gigabit Ethernet SFP transceivers can be installed for various fiber uplink distances.
An embedded user-friendly web interface helps users quickly and simply configure switches. SNMP v1/v2 are supported for management from a network management station. Telnet and SSH provide a safe and easy way for network administrators to manage the switch.
This Edge-Core switch also supports management functions through both IPv4 and IPv6.
Dimensions (W x D x H) cm: 44 x 35 x 4.45
Product specifications:
General Features:
Description 24 10/100/1000BASE-T RJ-45 PoE ports; 2 GE SFP slots
PoE Features:
802.3af and 802.3at PoE
Max. Power Output Per Port : 30W
PoE Power Budget : 190W
Power Management : Power On/Off per Port
L2 Features:
Auto MDI/MDIX
Auto-negotiation
Flow Control
IGMP Snooping v1 | v2 | v3
Immediate Leave
Jumbo Frame
Link Aggregation : IEEE 802.3ad with LACP (Dynamic)
Spanning Tree : IEEE 802.1D (STP) | IEEE 802.1w (RSTP) | Auto Edge Port
Storm Control Broadcast | Multicast | Un-known Unicast
VLAN IEEE 802.1Q Tagged Based | Private VLAN | Port Based | Voice VLAN
VLAN Group : 4K
QoS Features:
CoS IEEE 802.1p | IP Precedence | DSCP | TCP/UDP | ACL
H/W Queues : 8
Priority Queue Scheduling WRR | Strict Priority | Hybrid
Rate Limiting Ingress | Egress
Security Features:
ACL L2/L3/L4
HTTP and SSL (Secured Web)
IEEE 802.1x Port-based | MAC-based | VLAN Assignment | Guest VLAN | QoS assignment
IP Source Guard
MAC Filter
Port Security (MAC Based) Static | Dynamic
RADIUS (RFC2138) Authentication | Accounting
SSH v1.5/ v2.0 (Secured Telnet Session) Yes
TACACS+ Accounting
Username/Password Authentication Local | Remote
Management Features
Cable Diagnostic
CLI
DHCP Client | Relay | Option 82 | Snooping
DNS Client | Proxy
Event/ Error Log Local Flash | Remote Server via System Log (RFC3164)
LLDP
Loop Detection
Port Mirroring One to One | One to Many
RMON RMON I (1,2,3 & 9 groups)
sFlow
SNMP (Agent) v1 | v2c | v3
SNTP
Software Download / Upgrade HTTP
Telnet (RFC854)
UPnP
Web Based Management
Web Interface
IPv6 Features:
IPv6 Address Types Unicast
IPv6 Management SNMP over IPv6 | Remote IPv6 Ping | HTTP over IPv6 | DHCP IPv6
IPv6 Neighbor Discovery
Stateless Auto-configuration
