17″ Inch TFT LCD Monitor
-
Surface Acoustic Wave (SAW) Touch Panel
-
RS232 or USB Touch interface
-
Scratch Resistive touch Panel (Straight Glass, no overlay)
-
250 Nits (cd/m²
-
Very Bright, clear picture
-
VESA Mounting points
?
|
Viewing Area |
17″ TFT |
|
Resolution |
1280 x 1024 @75Hz |
|
Response time |
16 ms |
|
Contrast Ratio |
400:1 |
|
Brightness |
250 cd/m² |
|
Display Colours |
16.7 million |
|
View Angle |
150º (H) / 120º (V) |
|
VGA Signal |
Analog VGA |
|
Scan Frequency |
H:31~80 kHz / V: 60~75 Hz |
|
Controls |
Brightness, Contrast, H-Phase, V-Phase, size |
|
Touch Panel |
Surface Acoustic Wave Touch screen |
|
Touch Interface |
RS232 or USB |
|
Power Supply |
External Power Adapter AC 100~240V, 50/60Hz |
|
Consumption (Max) |
60 W |
|
Operating Temperature |
0 ~ 40 ºC |
|
Operating Humidity |
10 ~ 90% |
|
External Dimensions (W x D x H) |
459 x 165 x 408 mm |
|
EMC/Safety Standards |
CE, FCCB, TUV/GS, ETL.ETLC |
