Rugged Ergonomic lightweight Design
-
One handed operation
-
Solid State Heavy Duty Construction, No moving parts!
-
Operational after multiple drops from 1.2m onto concrete, on all axis.
The high-performing Dolphin 6100 can sustain up to 500 tumbles from 1 meter
-
Lithium Ion Battery with advanced Power Management System. 2 options available.
-
Powered by Adaptus™ Imaging technology 5.0
-
5300 VGA Area Imager/scanner with High-Vis bracket aimer
-
Windows CE 5.0
-
Marvell XScale PXA300 Processor
-
Standard 128Mb RAM, 128Mb non-volatile Flash memory.
-
WLAN: 802.11b
-
Standard Bluetooth® Class 2 V1.2
-
2.8″ QVGA 240×320 Transmissive active matrix colour display with touch screen.
-
28 Key Alpha/numeric-shifted alpha
?
|
Homebase |
Dolphin® 6100 HomeBase™, charging cradle with USB & RS232 communications ports plus extra well to charge extra battery |
|
|
D61EHB |
Dolphin® 6100 eBase™, charging cradle with Ethernet, USB & RS232 communications ports plus extra well to charge extra battery |
|
|
Charger |
D6BQCHG |
QuadCharger™ 4 slot Battery charger for Dolphin 6100/6500 |
|
Mobile Charger |
D60MC |
Dolphin® 6100 Mobile Charge Cable kit. Includes 12V vehicle charging adapter and terminal cup. |
|
Cables |
CAB-USB2AMiB2 |
Communication Cable USB A to USB mini for Homebase |
|
CAB-D61-U |
Dolphin® 6100 I/O Sync Cable – USB |
|
|
CAB-95-R |
RS232 Communication Cable |
|
|
Battery |
Spare Extended Battery for Dolphin 6000/6100 |
|
|
D61EXBCOVER |
Cover for Extended Battery for Dolphin® 6100 |
|
|
Stylus |
D60STYLUS |
Stylus and tether kit (3 Pcs) |
|
Screen Protector |
D61SCPROTECT |
Screen Protector for Dolphin 6100 (Pack of 10) |
|
Processor |
Marvell XScale PXA300 624 MHz |
|
|
Development Environment |
Honeywell SDK for Windows® CE 5.0 3rd party software: SOTI MobiControl (remote device management), Naurtech CETerm™ Terminal Emulation (TNVT, 3270, 5250) and ITScriptNet™ |
|
|
Operating Platform |
Windows CE 5.0 |
|
|
Memory |
128 MB RAM x 128 MB non-volatile synchronous Flash standard. |
|
|
Memory Expansion |
User accessible Micro SD Card up to 4GB with SDIO support |
|
|
Scan engine |
5300SR 2D Imager with Adaptus Technology and Laser Aimer. |
|
|
Symbologies support |
1D Linear |
Codabar, CODE 3 of 9 including PARAF, Interleaved 2 of 5, Code 2 of 5, Matrix 2 of 5, Code 11, Code 93, Code 128, UPC, EAN/JAN, RSS, PLessey, Posicode, Straight 2 of 5 IATA, straight 2 of 5 Industrial, Telepen, Trioptic Code, UCC/EAN-128, UPC-A |
|
2D |
PDF417, Maxicode, Data Matrix, QR Code, Aztec & Code 16K |
|
|
Composite & OCR Codes |
Aztec Mesas, Codablock F, EAN-UCC, RSS-14, OCR-A & OCR-B |
|
|
Postal Codes |
Postnet, Australian, British, Canadian, China, Japanese, KIX (Netherlands), Korea & Planet Code |
|
|
Keyboard |
28 Key shifted alpha Numeric, backlit. |
|
|
Display |
2.8″ QVGA (240 x 320 Portrait mode) colour Transmissive Active Matrix LCD display withTouch Screen |
|
|
Display Resolution |
240 x 320 Pixels |
|
|
I/O Ports |
Industrial grade mechanical connector supports: Integrated Speaker, Microphone and Headset jack |
|
|
Radio option Standard Bluetooth |
WLAN |
Dual Mode 802.11 b/g (11 Mbps/54 Mbps) with internal antenna |
|
WPAN |
Bluetooth® Class II (10 m) v2.0 Enhanced Data Rate (EDR) with on-board antenna. BQB certified |
|
|
Standard Battery |
Lithium ion 3.7V/2200 mAh |
|
|
Hot-swap |
||
|
Extended Battery |
Lithium ion 3.7V/3300 mAh |
|
|
Hot-swap |
||
|
Sealing |
IP54 rating (Water & Dust Resistant) |
|
|
Mechanical Shock |
Drop: Functional multiple drops from 1.2m onto concrete Tumbles: 500 1 m thumbles |
|
|
Electrical Static Discharge |
Air: 15kVdc Direct: 8kVdc |
|
|
H x W x D |
175 x 66 x 26.8 mm |
|
|
Weight |
250g with standard Battery |
|
|
operating Temp. |
-10 ~ 50°C |
|
|
Humidity |
up to 95% non condensing |
|
