Fully automatic scanning operation
-
Single-line mode for menu reading
-
Sleep mode with IR wake-up
-
Easy mounting integration
-
Small footprint
-
Custom configurable scan pattern
-
User-replaceable, single cable interface to host
-
Decoding of all standard 1D, RSS-14, RSS Limited and expanded RSS bar codes
-
OPOS and JPOS system compatible
|
Scan Lines |
Omni-Directional 20 lines Raster mode 4 lines Single line mode 1 line |
|
|
Scan Rate |
Omni-Directional 1650 scan lines/sec Raster mode: 320 scan lines/sec Single Line mode: 80 scan lines/sec |
|
|
Depth of Field(programmable) |
19mm-273mm for 13mil bar-codes at default setting |
|
|
Decoding Capability |
Autodiscriminates between following symbologies: |
|
|
All standard 1D bar codes, GS1 Databar™ & GS1 Databar™ expanded. |
||
|
System interfaces available |
RS-232 Light Pen Emulation Keyboard Wedge Stand alone Keyboard IBM 468x/469x USB Laser Emulation OCIA |
|
|
Height x Width x Depth |
Standard |
108 x 67 x 66mm |
|
with Short Pole |
208 x 67 x 66mm |
|
|
with Long Pole |
273 x 67 x 66mm |
|
|
Weight |
170g |
|
