Slim all-in-one design.
-
Can be used as multimedia Kiosk for self-service applications.
-
Customised with coloured bezels.
-
Long-life LED backlight LCD display.
-
Die-cast aluminium.
-
Optional 40GB Solid State hard drive.
-
Integrated Stereo Speakers.
-
Mobile Intel ® 945 GSE Express Chipset.
-
Diagnostic LED indicators.
-
Secure front access to Hard Drive.
-
Quick access to internal components.
-
Fan-less operation for increased reliability.
-
Energy Star 5.0 qualification.
-
Secure cable connections with positive latching connectors and cable strain relief.
?
|
Memory Upgrade |
NCR40R2000 |
DDR2 2 GB Memory module to upgrade memory in the base terminal |
|
MSR |
3-track ISO MSR with USB cable. Mounts on right side of terminal. |
|
|
MSR & Biometric Reader |
3-track ISO MSR & Biometric Reader with USB cable. Mounts on right side of terminal. |
|
|
VFD Display |
NCR25TM202 |
Top mount 2 line VFD display |
|
2nd LCD Display |
NCR5942H15-B |
15″ LCD Display with power and short VGA cable |
|
NCR25PDBASE |
Display base for 2nd LCD Display |
|
|
NCR25VPOLE |
Pole & VESA mount for 2nd LCD Display |
|
|
Presentation Scanner |
NCR7884-R |
RealScan 7884 Presentation Scanner |
|
Printer |
NCR7197G |
NCR Thermal Receipt printer |
|
CPU |
Intel Atom N270 Processor (533MHz FSB, 512 L2 Cache) |
|
Memory |
1GB SODIMM DDR2 up to 2GB (Single Slot) |
|
Storage media |
2.5-inch 160GB SATA Hard Disk Drive |
|
USB Ports |
4 total, |
|
Serial Ports |
4 total – Powered RS-232 (selectable 0/5/12V) -3 External DB9 -1 Internal (for 2×20) or external DB9 (optional) |
|
Other Ports |
1 DVI port or VGA port (only one can be used) |
|
Operating Systems |
Windows ® Embedded POSReady 2009 |
|
Power Management |
MEPS Level V (87% efficient external power supply) External power supply enables easy swap |
|
Customer Display Mounting |
V2x20 VFD Terminal Mount 2×20 VFD Pole Mount 6.5″, 12.1″, 15″ Graphical LCD rear display |
|
Case |
Die Cast Aluminium with VESA mount |
|
Diagnostic |
2 Colour LED’s provide diagnostic feedback |
|
Energy Star 5.0 Qualification |
Windows and SLEPOS 11 operating systems purchased from NCR are defaulted to support ENERGY STAR 5.0 power settings. If an operating system is not purchased from NCR, the RealPOS 40 will ship with an open source Linux operating system defaulted to support ENERGY STAR 5.0 power settings for compliance purposes. |
|
Display |
On-board VGA, DVI for Single video display support |
|
Support software |
NCR OPOS and JavaPOS support |
|
Dimensions (W x D x H) |
Terminal only: 370mm x 86mm x 323mm |
|
Weight |
Terminal with power supply: 6.7 Kg |
