PC POS Touch System
-
Resistive or Projective capacitive touch screen
-
15” LCD 1024 x 768 resolution
-
Spill-resistant design (IP44 capable) to prevent careless spill and provide easy cleaning for a wide range of applications
-
Equipped with Intel Pine View Dual Core D525 1.8 GHz CPU 1M Cache and DDR3 memory
-
Fan-free design boasting quiet and anti-dust features
-
Aluminium die-cast housing design for efficient cooling
-
RAID 1 (Disk Mirroring) support to backup important data (Optional)
-
Push-open cover to protect power switch from accidental shutdown
-
New Gen 7 Slim line Base (Patent pending)
-
Optional Gen 8 slim base, which can have build in Power supply and Powered USB Modules
|
Rear Display |
PFPD350B-U |
2 Line 20 Character LCD Display mounted on the rear top of display for the KS series with USB Interface |
|
PFPD2608B-U |
2 Line 20 Character VFD Display mounted on the rear top of display for the KS series with USB Interface |
|
| MSR |
PFSA105B3-U |
MSR track 1, 2 & 3 for the XT-3015 |
| MSR with RFID module |
PFSA305B3RF31-U |
MSR track 1, 2 & 3 and RFID module for the XT-3015 |
| MSR with Fingerprint reader module |
PFSA305B3FP-U |
MSR track 1, 2 & 3 and Fingerprint module for the XT-3015 |
| MSR with RFID & Fingerprint reader module |
PFSA305B3RF31FP-U |
MSR track 1, 2 & 3 and RFID & Fingerprint module for the XT-3015 |
| 2nd LCD Display |
PFLM3014BF |
14″ inch 2nd Bezel free LCD Display rear mounted for the XT-Series |
|
PFTM3014BF |
14″ inch 2nd Bezel free Touch LCD Display rear mounted for the XT-Series |
|
|
PFLM3010BF |
9.7″ inch 2nd Bezel free LCD Display rear mounted for the XT-Series |
|
|
PFPD6607B-U |
7″ colour LCD customer display(800*480 resolution) with PD-26XX/2300 command simulation and other fancy features rear mounted, USB interface for XT-series |
|
|
UPS Battery |
Rechargeable UPS Battery (can only be used if optional ups module is fitted and Gen 8 base is used. |
|
|
Cables |
RJ45 to DB9 Converter Cable |
|
|
Optional Parallel Cable |
||
|
Cable to be able to fire 24V Cash Drawers |
|
CPU |
Intel Pine View Dual Core D525 1.8 GHz / 1M Cache CPU |
|
Memory |
DDR3 800 MHz, SO-DIMM socket x 1, max 4 GB, default 1GB |
|
Storage |
We stock Standard 32G SSD Also available with higher spec SSD or 3.5 inch 320GB Hard Disk Drive Optional 2nd HDD with RAID Function |
|
LCD |
15″ TFT LCD Display |
|
Brightness |
250 nits |
|
Resolution |
1024 x 768 |
|
Touch Panel |
5-wire Resistive USB I/F, optional IR Touch |
|
Connectivity |
4 RS-232 Ports (3 x DB9, 1 x RJ45) with 5V/12V support |
|
1 Parallel Port (Optional Proprietary Cable) |
|
|
5 USB Ports 1 Proprietary USB port for side mount optional devices |
|
|
VGA Port for 2nd Display (D-Sub with 12V Power for Posiflex LCD Monitors) |
|
|
1 Cash Drawer Port (Controls 2 drawers with optional Y-cable) |
|
|
Dual 10/100/1000Mb Ethernet Ports |
|
|
UPS Port |
|
|
Power on wake up |
Through Alarm, LAN or Modem |
|
Operating condition |
0°~40°C, 20~90% Relative Humidity |
|
Sound |
2W Speaker in the main unit |
|
Size (W x D x H) |
372mm x 320mm x 253 mm |
|
Weight |
5.6 Kg |
